GM 9.5 Inch Axle- Differential, Ring and Pinion, Gear & Axle Parts Catalog

Click Page to Enlarge

Additional Components For this Application

Limited Slip Posi Positraction Eaton Truetrac True Track Auburn Gear DifferentialLimited-Slip Differentials

Automatic Locking Differential Locker Detroit Locker Lockright GrizzlyAutomatic Locking Differentials

Selectable Locker Locking Differential ARB Air Eaton ELocker Zip Harrop Push Button DifferentialSelectable Locking Differentials

Car Truck Axle Shaft Rear End U Joint Axle Bearing Seal KitAxle Shafts & Axle Bearing Kits

GM 9.5″ Rear Axle – Common Applications

1979 thru 2013 – 14 Bolt Cover / 2014 & Up – 12 Bolt Cover

2014-2019   |   Cadillac Escalade
2002-2013   |   Chevrolet Avalanche 1500
2002-2006   |   Chevrolet Avalanche 2500
1979-1988   |   Chevrolet C20
1988-1997   |   Chevrolet C1500
1988-1997   |   Chevrolet C2500
1996-2019   |   Chevrolet Express Van 2500
1979-1995   |   Chevrolet G20
1988-1997   |   Chevrolet K10/ K1500
1979-1997   |   Chevrolet K20/K2500
1999-2019   |   Chevrolet Silverado 1500
2001-2007   |   Chevrolet Silverado HD 1500
1999-2013   |   Chevrolet Silverado 2500
1997-2019   |   Chevrolet Suburban 1/2 Ton
1981-2019   |   Chevrolet Suburban 3/4 Ton
2003-2006   |   Chevrolet SSR
1997-2016   |   Chevrolet Tahoe 1500

1988-1997   |   GMC C15/ C1500
1979-1997   |   GMC C25/ C2500
1992-1997   |   GMC G35/ G3500
1988-1997   |   GMC K15/ K1500
2014-2019   |   GMC Savana 1500
1996-2019   |   GMC Savana 2500
1998-2019   |   GMC Sierra Denali
1999-2019   |   GMC Sierra 1500
2007-2007   |   GMC Sierra 1500 HD
1999-2013   |   GMC Sierra 2500
1981-2000   |   GMC Suburban 3/4 Ton
1992-2019   |   GMC Yukon 1500
2000-2019   |   GMC Yukon XL 1500
1997-2019   |   GMC Yukon 2500
1997-2019   |   GMC Yukon XL 2500
2002-2009   |   Hummer H2
2008-2008   |   Saab 9 7x

GM 9.5″ 14-Bolt Rear Axle – Exploded View

GM 9.5 14-Bolt Exploded View

Click to Enlarge
GM 9.5″ 12-Bolt Rear Axle – Exploded View
GM 9.5 12 Bolt Rear - Parts DiagramClick to Enlarge
